iPower i6AC 80W Balance charger/discharger

$159.00

  • PB/Li-Ion/LiPo/LiFe/NiCad/NiMh Compatible
  • 80w, 110v – 240v (DC 11-18v)
  • Professional Balance charger/discharger

10 in stock

Description



iPower / Airsoft

i6AC 80W Professional Balance charger/discharger





The i6AC is a more complex to operate, advanced level battery charger for the more invested hobbyist. The charger comes with 3 different balancing connectors, AC power lead & instruction manuals. This charger is capable of charging a large variety of battery types with manual control of how you want to charge the battery. LED screen is easy to use while charging / discharging and monitoring your battery.

This charger is recommend over the smaller manual chargers (such as the IP3025)  if you have many batteries to charge and want to maintain the health of your batteries better!





Charge procedure:

  1. Insert the AC power cord into the charger.
  2. Insert the AC cord into a wall socket (100-240V) & plug in charging leads.
  3. Select the battery type LiPo/LiFe/NiMH.
  4. Select cell count (lipo/liFe/li-ion/li-Hv), charge mode & charge Amp output.
  5. Hold Start and confirm to start charging (Error message will occur if input of battery is incorrect).
  6. Charger will sound alarm once charging is complete or Error while charging occurs.





Specifications:

  • Operating voltage range: DC 11.0-18.0V
  • AC input: 100-240V  50/60Hz
  • Circuit power: Max charge power 80W / Max discharge power 10W
  • Charge current range: 0.1 – 8.0 A
  • Discharge current range: 0.1 – 2.0 A
  • Current drain for balancing LiPo: 460mAh / Cell
  • NiCd / NiMh battery cell count: 1 – 15 cells
  • Li-ion / LiPo / LiFe: 1 – 6 cells
  • Pb battery voltage: 2 – 20V
  • Weight: 590g (net weight)
  • Dimensions: 135mm x 145mm x 43mm







Additional information

Weight .156 kg
Dimensions 12 × 11 × 5 cm
